1. Main characteristics

lIndustrial design, adjust to high temperature and other bad environments;

lSimulated manpower friction card issuers better adaptability to various deformed cards;

lWatchdog of hardware and embedded operating system to ensure properly running;

lPre-dispense function accelerate dispensing speed;

lConnectable with the vehicle detector to achieve card issuing and one car, one card”;

lAutomatic buzzer alarm when no cards, fewer cards or failure.

lProvide both RS232 and I/O voltage control interface;

lAutomatic buzzer alarm when errors occur, automatic reset after 100 seconds alarm;

lCapacity of card stacker is more than 40pcs, automatic buzzer alarm when the withdrawing stacker is full;

lSlide card stacker with a capacity of 40pc;

lAdjustable of card stacker with a capacity of 120pc each;

lAutomatic withdrawal to prevent card lost (only for TCD800F series

lSlide design to make installation and disassembling easier;

lMolded production to ensure high consistency of precision and quality.

2. Main technical data

lOperating voltage: 24VDC (max current 2A, static current 0.1A)

lOperating temperature: -20℃ to 85℃

lOperating humidity: 30-90% (comparatively)

lUse condition: install in bin

lCard available: width: 54+/-0.5mm

Length: 85+/-0.5mm

lThickness: 0.3-2.5mm (adjustable)

lCard material: Paper or Polyester card

lNet weight of card dispenser: 2.0kg (including the briquette)

lTime of issuing: max0.5s

lCapacity of stacker: 150pcs (0.8mm), 100pcs available when an extra stacker is needed
