Specifications:
Framework: 304(standard)/202/316 Grade Stainless Steel/Iron
Shell’ size: 1400*1500*1000mm (Standard)
Finish: Brushed surface (default)/polishing surface/Hot-galvanized
Operation voltage: AC220V (50Hz)/AC (110-240) (60Hz); Main-board
voltage: DC 24V
Control panel with count and LED digital function
Control panel with alarm and sounds indication functions (optional)
Transit speed: 20-30 persons per minute
Work environment: Indoor/outdoor
Temperature: -20 ℃ to 60 ℃
Emergency and Traffic-light function
Half High Turnstile Functions:
Reposition automatically
Bi-direction passing
The arms always be at the closing state
The gate turns 90°at a time
Input Interface: Dry Contact Digital Signal
Three passing modes for both in or out:
- Free in & out (without locked);
- Limited in & out (controlled by access control system);
- Forbidden in & out (locked & without control by the access
control system).
If no passage is completed, the release will be cancelled after an
adjustable time.
Optiaonal LED direction indicator
Optional indication of inside counter or outside counter
With interface of switch, compatible with all the access controller
Standard Accessories and Optional Extras:
Alternative materials, finishes and custom design
- Top material can be supplied to suit customer requirements
- Finish and color optional
Access control system integration (Refer to our access control
system of C-L2000 or C-T2000)
- Integration of customer supplied readers inside
- Card reader pedestals
Ticket system integration
Status lights:
- LED display status lights flush mounted within the turnstile top,
top face.
- The green badge symbol is continuously illuminated indicating
passage is available.
- Upon authorization a green arrow will illuminate in the direction
of passage authorization while in the opposite direction a red
cross symbol will illuminate to indicate the unit is not available
for use or is already in use.
Push button control
- Simple remote push button by wireless console
- Single push-button casework or top mounted
