    Driveway Car Digital Vehicle Loop Detector One Channel Standard Relay VD108

    Ask Lasest Price
    Brand Name : Koten
    Certification : CE
    Price : Negotiable
    Delivery Time : 3-45days depends on order quantity
    Payment Terms : by T/T, Western Union, Money Gram, and Paypal, 30% made in advance the balance paid before shipment
    Supply Ability : 200units per month
    Model Number : VD108
    • Product Details
    • Company Profile

    Driveway Car Digital Vehicle Loop Detector One Channel Standard Relay VD108

    Driveway Car Digital Vehicle Loop Detector One Channel Standard Relay VD108


    Loop Detector

    Product name: Loop Detector
    Item: VD108
    Details

    1. Introduction

    VD-108B single loop detector is used for detecting vehicles and which were fit for parking lots, vehicle roll station or controlling traffic light systems .and so on.. The difference between VD-108B and TDL300 is the way of output. The way of output of VD-108B is TTL and the way of which of TDL300 is OCL. Any other technical reference data is same.


    2. Technical data

    (1) Supply Voltage: 7-12VDC@20mA

    (2)Frequency range: 29 KHz-90 KHz

    (3)Reaction time: 100ms

    (4)Output Delay: 2s (alternative)

    (5)Sensitivity: 0.02%-0.2% adjustable in 4 increments.

    (6)Environmental compensation: Automatic drift compensation

    (7)Loop inductance: 80uH-300Uh (include the connecting wiring)

    Ideal 150Uh (41 KHz)

    (8)Loop connection wiring: Max.5 meters, Twisted at least 20 times per meter.

    (9) Storage temp: -40C-+85C

    (10)Operating temp: -20C-+55C

    (11)Relative humidity95%

    (12)Package: standard relay package

    (13)Dimensions: 27mm (L)*21mm (W)*37mm (H)
