Function introduction
Sensor probe: imported thermal infrared imaging probe, compared
with ordinary infrared receiver on the market, has the advantages
of high sensitivity, high pixel, high resolution, area array
imaging, etc;
High passing rate: normal slow walking through, face side view
indicator light, passing rate ≈ 40-60 people / min;
Avoid missing inspection: the product design conforms to the
ergonomics, which can ensure that the subject cannot avoid the
probe and the inspection
Detection accuracy: the detection result can be accurate to two
decimal places. Under normal room temperature, the temperature
error is ± 0.5 ℃; under the stop and stay mode, the temperature
error is no more than ± 0.3 ℃;
Irradiation angle: large area conical fan type;
System function: the number of green light prompt, high temperature
alarm red light prompt, number of records;
Audible and visual alarm: when the temperature of the tested person
is abnormal through the temperature measuring door, the red signal
light flashes, and gives a sound prompt to the detection personnel,
and the number of alarms can be stored;
Intelligent statistics: intelligent passenger flow and alarm
counting function, which can automatically count the number of
people passing and the number of alarms
Very low power consumption: normal working power 1000W;
Detection height: the probe can move up and down, adapt to
different height, different age groups;
Parameter setting: the main parameters such as sensitivity,
accuracy, temperature can be debugged according to the customer's
use scenario;
Working mode: ① normal passing mode; ② slow side mode; ③ stop stop
mode;
Positioning system: tracking personnel's real-time position through
ultrasonic microwave
Detection distance: ＜ 50cm
Optional module: blackbody automatic calibration module
Basic parameters
Product model: CWM2020T
Working humidity: 95%, non condensing
Temperature measurement range: 25 ℃ ~ 48 ℃
Temperature measurement accuracy: ± 0.5 ℃ (at room temperature)
± 0.3 ℃ (constant room temperature) in specific mode
Working voltage: wide voltage AC80-250V, 50-60Hz
Working frequency: automatic or manual adjustment according to the
installation environment
Power: 100W
Net weight: 50kg
Channel size: 1950mm (H) × 700mm (W) × 500mm (d)
Boundary dimension: 2150mm (H) × 780mm (W) × 500mm (d) (if there is any change to the boundary, it will not be
notified, the actual object shall prevail)
